Electrical troubleshooting & minor network outages : UPS , pass-through , 12V 4G/5G router , 100W USB-C laptop , LED , 120–160W panels (MPPT) & 12V charging - 2025 guide
Power outage, micro-outages, internet box HS, building works, thunderstorms: keep the job , the connection and the security on with a LiFePO4 512–700 Wh power station equipped with UPS / pass-through , USB-C 100 W , 12 V regulated , AC 230 V pure sine and MPPT for foldable panels 120–160 W. In this guide, we build a plan B for laptop , portable screen , 4G/5G 12 V router , LED lighting , small domestic loads, with ready scenarios , tables and a LymobileShop selection.
See 512–700 Wh (LiFePO4) stations | 120–160 W foldable panels (MPPT) | 100/240 W USB-C cables (5A e-marker) | 65–100 W GaN chargers |20k/30k power banks
1) Common breakdowns & what to maintain
- Micro-cuts & mains switch : laptop/box restarts, video calls cut off → UPS required.
- HS Internet Box (local/ISP outage): keep a 12V 4G/5G router ready.
- Works/storm : prolonged outage → switch to 700 Wh station + 160 W panel .
- Security lighting : Low-consumption LEDs for key areas (office/corridor/kitchen).
Priorities: productivity (laptop + screen), connectivity (4G/5G), safe lighting , 6–12 h battery life , silence .
2) Concept: LiFePO4 station + UPS + pass-through + MPPT
- LiFePO4 512–700 Wh : thermal safety, longevity, stability.
- UPS : automatic mains → battery switch to avoid shutting down sensitive devices.
- Pass-through : powers while charging (practical for box/router/LAN/laptop).
- Built-in MPPT : maximum efficiency with 120–160 W panel.
- Display : % + W in/out → you control consumption directly.
3) Size 512/700 Wh: work, network, light
- USB-C Laptop : 45–80 W depending on model/use.
- USB-C portable display : 10–15 W (13–16″).
- 4G/5G Router 12V : 8–12W (stable flow).
- LED : 3–10 W per lamp (office, hallway).
Quick rule : 512 Wh = 1 day “work + network + LED”; 700 Wh = long video margin + extended outage.
4) Key ports: USB-C 100W , 12V regulated , AC sine wave
- USB-C Power Delivery 100W : laptop/monitor/hubs (efficiency & silence). Uses a 5A e-marker cable .
- 12V regulated : 4G/5G router, small LEDs, avoids AC losses.
- USB-A : phones, USB modems, accessories.
- AC 230 V (pure sine) : non-USB-C screens, proprietary chargers → as a last resort .
5) Backup network: 4G/5G 12V router & sharing
- 4G/5G 12V router : more stable than smartphone sharing, ideal for video/VPN.
- Optimization : near a window, clear antenna, band-lock if possible; lower Wi-Fi power if you are alone.
- Failover : turns off the box, switches to 4G/5G, continues in USB-C 100 W.
- Powerbanks 20k/30k : modem/phone relay while the station recharges (solar/12V).
6) UPS & pass-through: uninterrupted continuity
- UPS : Place the station between the mains and your IT power strip (laptop/monitor/router). When the power goes out, the station takes over without switching off .
- Pass-through : useful for holding long video calls while recharging the station when the power returns.
- Tips : Test the switch off while not in production; avoid overloading the AC outlet; favor USB-C/12V.
7) LED lighting & security (home/office)
- 12V 3–10W LED : sufficient for working/moving.
- Areas to light : office, hallway, kitchen; USB children's night light.
- Safety : no flame; station in the shade , ventilated , not covered .
- Organization : a 12 V garland marks the passage → zero fall.
8) Solar 120–160 W (MPPT): smart top-up
- Realistic output : 120 W → 70–95 W usable; 160 W → 110–135 W (angle/short cables).
- Gain : 2–3 hours of good sun → +220 to +405 Wh (160 W), enough to compensate for the router + LED + part of the laptop.
- Placement : oriented kickstands, avoid balcony/vegetation shadows, MC4→DC short & thick.
9) 12V car charging & network connection
- 12V input : 60–120W typical (depending on socket/fuse). Plug in after starting , unplug before stopping .
- Thermal : ventilated trunk, station in the shade, never covered during charging.
- Workflow : during a long break, take the opportunity to recharge while traveling (shopping/appointments), then come back with 40–60% recovered.
10) Ready scenarios
Home office — micro-cuts
- Station : 512 Wh with UPS .
- Set : 55W USB-C laptop, 12W portable display, 10W 4G/5G router, 5W LED.
- Tip : connect screen + laptop via direct USB-C → no AC fan, battery life ↑.
HS Internet Box — 4G/5G failover
- Station : 512–700 Wh.
- Set : 4G/5G 12V router, USB-C laptop/screen, LED.
- Plus : 120–160 W 2–3 h/day to get back to everyday life.
Extended outage (storm/works)
- Station : 700 Wh + 160 W panel.
- Set : 2–4 h laptop, 10 W router, 10–20 Wh/h LED, 20k power banks for smartphones.
- Recharge : solar afternoon + 12 V at the end of the day.
Building office - continuity
- Station : 512 Wh pass-through on IT power strip.
- Set : USB-C laptop, portable screen, backup 4G/5G router, LED.
- Tip : Monthly switch test, labels on critical cables.
11) Practical tables
11.1 Typical consumption (emergency)
| Equipment | Power (≈) | Energy/d (≈) | Notes |
|---|---|---|---|
| USB-C Laptop | 45–80 W | 120–300 Wh | Depending on CPU/GPU load |
| USB-C portable display | 10–15 W | 40–90 Wh | 13–16″ |
| 4G/5G 12V Router | 8–12 W | 60–100 Wh | Signal/Network |
| LED (office/hallway) | 3–10 W | 10–60 Wh | Dimmable |
| Smartphones (×2–4) | — | 30–80 Wh | USB-A/C |
11.2 Station × recommended sign
| Config | Ability | Sign | Charge (sun) |
|---|---|---|---|
| Home office | ~512 Wh | 120 W | ~4–6 h |
| Extended cut | ~700 Wh | 160 W | ~4–7 h |
11.3 Sections & fuses (12–20 V DC)
| Line | Fluent | Cable (≈) | Fuse |
|---|---|---|---|
| 12V router (10–12W) | ~1 A | 1–1.5 mm² | 2 A |
| LED distribution | 2–5 A | 1.5–2.5 mm² | 5 A |
| DC distributor | 5–10 A | 2.5–4 mm² | 10 A |
11.4 Midday Solar (120–160 W, MPPT)
| Sign | Useful power ~ | 2 hours of sunshine | 3 hours of sunshine |
|---|---|---|---|
| 120 W | 70–95 W | 140–190 Wh | 210–285 Wh |
| 160 W | 110–135 W | 220–270 Wh | 330–405 Wh |
12) “Cut-off ready in 60 seconds” checklist
- Station : 512–700 Wh LiFePO4 with UPS / pass-through , MPPT .
- Ports : USB-C 100W , 12V regulated , AC sine (backup).
- Network : 4G/5G 12V router configured (SIM card ready).
- Lighting : 12V LED garland/lamp in hallway/office.
- Solar : 120–160 W panel accessible, MC4/DC ready.
- 12V car : cable within reach, locate the socket.
- Cables : USB-C 5A e-marker , fused DC splitter, labels.
- Test : monthly UPS tipping exercise (1 min).
13) LymobileShop Selection
Stations ~512 Wh — office continuity
- Features : UPS / pass-through , 12 V regulated , USB-C 100 W , AC 500–700 W, MPPT .
- Uses : laptop + USB-C screen, 4G/5G router, LED.
Stations ~700 Wh — extended outage
- Advantages : autonomy ↑, AC 700–1000 W, W in/out display.
- Uses : long video calls, multiple devices, daily solar top-up.
120–160 W Foldable Panels
- Pros : MPPT , 70–135 W usable, MC4/DC, kickstands.
Powerbanks 20k/30k — network relay
- Advantages : PD 20–30 W for modem/phone; fast charging on station.
Cables & Chargers
- USB-C 100/240 W (5A e-marker) — laptop/screen/hubs.
- 65–100 W GaN chargers — fast mains charging.
14) FAQ on electrical/network failures
UPS and pass-through, are they the same?
No. UPS = automatic switchover without cutting off; pass-through = supply power while charging (useful but not a UPS in itself).
USB-C 100W or AC for laptop?
USB-C direct = better battery life & less noise. AC is used for proprietary chargers.
Is 160W solar enough for a day of teleworking?
Yes, 2–3 hours of good sun adds +220–405 Wh , enough to cover the router + LED and part of the laptop.
Can I connect a NAS/box to the station?
Yes, but check the total power and favor the UPS to avoid any unexpected shutdown of the storage.
Car → office crossing?
Recharge at 12V during the journey, then pass-through to the office to leave fully charged.
